MSi B560M-A PRO
M.2 SHIELD FROZR:
World’s fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 SHIELD FROZR is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance.
FROZR AI COOLING:
Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.
FULLY CONTROLLABLE IN BIOS AND SOFTWARE:
MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.
HIGH-BANDWIDTH AND LOW-LATENCY NETWORK:
2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.
A HUGE STEP OF DDR PERFORMANCE:
MSI OC LAB does not merely work hard on extreme overclocking. Compare to B460 motherboard memory XMP profile, MSI does have great improvement on performance and efficiency for B560. Easy to enable XMP profile with auto power settings to get the best memory speed and stability.
CORE BOOST:
Core Boost technology combines MSI’s premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.
Specifications:
CPU:
| Chipset | Intel B560 |
| CPU Socket | LGA 1200 |
Back Panel I/O:
| USB | 2 x USB 2.0 Type-A 4 x USB 3.1 / USB 3.2 Gen 1 Type-A |
| Thunderbolt | None |
| Display | 1 x HDMI 2.0b 1 x VGA |
| Audio | 3 x 3.5 mm |
| Ethernet / Controller | 1 x Realtek 8125B 2.5Gigabit |
| PS/2 | 1 x Combo |
Memory:
| Memory Slots | 2 x 288-Pin |
| Memory Support | DDR4 2133, 2666, 2933, 3200, 4700, 5200 MHz |
| Maximum Capacity | 64 GB |
| Channel Architecture | Dual Channel |
| ECC Support | Non-ECC Unbuffered |
Storage Expansion:
| SATA | 6 x SATA III |
| M.2 | 1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4, PCIe 3.0 x4, SATA III) |
| U.2 | None |
| Optane Memory Support | Yes |
Internal I/O:
| Expansion Slots | 1 x PCIe 4.0 x16 2 x PCIe 3.0 x1 |
| USB | 1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port) 2 x USB 2.0 Header (Supports 4 USB Type-A Port) |
| Air Cooling | 1 x 4-Pin CPU 2 x 4-Pin System |
| Power Connectors | 1 x 24-Pin Mainboard 1 x 8-Pin ATX |
| Security | Chassis Intrusion, TPM Module |
| Audio | 1 x Speaker |
| Diagnostics | Clear CMOS |
| Legacy | 1 x Serial |
BIOS:
| ROM | 256 Mb |
Front Panel I/O:
| I/O Connection Headers | AAFP, USB 3.1 / USB 3.2 Gen 1 |
Audio:
| Audio Codec | Realtek ALC897 (7.1-Channel) |
Physical:
| Form Factor | Micro-ATX |
| Dimensions | 8.0 x 9.3″ / 20.3 x 23.6 cm |
